MT0006| Piezoelectric Speaker

Piezoelectric SpeakerModel：MT0006

Piezoelectric speaker which is widely used in digital products, general instruments, household applications, voice prompt and music player under different situations, voice relay and alteration in special fields and industrials. Based on the multilayer technology, high conversion efficiency and high SPL out put.

Request a sample

Features

- Simple acoustic design which can be installed in a narrow and flat space
- Milliwatt level of power consumption and high conversion efficiency, which makes it used widely
- The product won’t cause any electromagnetic interference to surrounding electronic devices and has excellent anti-interference ability.

Dimensions

Specifications

Item	Specifications
Sound Pressure Level	80dB/Min
Electrostatic capacity	1200±30%nF
Resonant freq.(F0)	800±100Hz
Frequency range	300~20000Hz
Max.Voltage	16 Vp-p
Operating Temperature	-20~+70℃
Storage Temperature	-30~+85℃
