AK2 Ultrasonic Sensor

AK2 Ultrasonic SensorModel：TK0158

The ultrasonic assembled sensor is an assembled ultrasonic sensor module, which consists of sensor, silicone ring, plastic housing and cable. It can be connected directly with the signal processing module, and is the key component of a parking system.

Request a sample

Features

- Strong range measuring ability

- Meet the standard of AK2

- High accuracy and reliability

- Built-in circuit which matches the self-developed transducer

Specifications

Item	Specifications
Resonant frequency	55.5 ± 1.0 kHz
Ring time	≤1.5ms
Directivity(deg) X-axis	90°±10°
Directivity(deg) Y-axis	45°±10°
Operating voltage	140Vp-p

Applications

- Intelligent parking systems

- Blind spot detection systems

- Obstacle avoidance systems
